Specification:
Children Test Finger / Children Test
Finger19
1, According to : GB4706.1、IEC61032-1997 and UL
2, Children Test Finger 19 Probe is the necessary appliance to
prevent electic shock for household and similar electrical problem
Technical Parameters:
1, Knurled Finger Diameter: 5.6mm
2, Knurled Finger Length :44mm
3, Head Radius:2.8mm
4,The First Handle
Diameter: 101.6mm
5, The First Handle Length:101.6mm
6, The Second Handle Diameter:25.4mm
7, The Second Handle Length:464.3mm
8, Reference Standards: GB4706.1 、IEC61032:1997 Figure 13,
Application:
1, The metal parts of the Test Probe can not touch the
live parts or not close to hazardous parts, plastic dam-board can not be entered .The reference standards are different ,please according to related standards
on the detailed test . It is only based on IEC 61032 & GB16842
Note: Children
Test Finger 19 is made of precision stainless steel, putting down and taking up slightly when
using, and pay attention to maintenance

|
